Description
Magtrol DES 411/111, bộ nguồn kích từ Magtrol
Magtrol DES 411/111 là bộ nguồn kích từ/nguồn cấp điều khiển cho dynamometer (băng thử động cơ) của hãng Magtrol
Ứng dụng chính Magtrol
- Đo và giám sát tải trọng từ load cell/strain gauge.
- Dùng trong máy bốc dỡ, nâng hạ và thiết bị xử lý vật liệu, đặc biệt có ứng dụng thực tế trong máy loading/unloading than.
- Giám sát quá tải: thiết bị có các mức cảnh báo/level detector và tiếp điểm relay.
- Đưa tín hiệu về PLC/DCS/SCADA thông qua ngõ ra analog.
- Có thể sử dụng trong các hệ thống cân và giám sát lực công nghiệp.
Model Magtrol
| Magtrol 234-411-000-111
Item: DES 411/111 Kit for Dyno 65, 115 & 1WB15 Kit dynamometer excitation supply for series 65, 115 and 15 dynamometer, in aluminium housing, with 5m cable between DES411 and DSP6001/7000 and 1.5m cable between DES411 and dyno |
Magtrol vietnam, Torque Transducers Magtrol, Speed Sensors Magtrol, Brake Systems Magtrol |
| Magtrol 234-401-000-222
Item: TSC 401/222 FOR DYNO 65, 115 & 15 Torque-Speed Conditioner for 65, 115 and 15 series dynamometers suitable for DSP6001/7000 with 2x 1.5m cables between TSC401 and dynamometer |
Magtrol vietnam, Torque Transducers Magtrol, Speed Sensors Magtrol, Brake Systems Magtrol |
| Magtrol 234-401-000-222
Item: TSC 401/222 FOR DYNO 65, 115 & 15 Torque-Speed Conditioner for 65, 115 and 15 series dynamometers suitable for DSP6001/7000 with 2x 1.5m cables between TSC401 and dynamometer |
Magtrol vietnam, Torque Transducers Magtrol, Speed Sensors Magtrol, Brake Systems Magtrol |
| Magtrol 88M372-0500
Item: TORQUE-SPEED CABLE 14M/15F (DSP TO TSC/DYNO) 5m Torque/speed cable 14-pin male – 15-pin female for dynamometers / TSC with DSP6001 / 700x electronic, length 5m |
Magtrol vietnam, Torque Transducers Magtrol, Speed Sensors Magtrol, Brake Systems Magtrol |
| Magtrol SPECIALITEM
Item CW-ENR.004 FOR 1WB65 Chiller water cooling system Cooling power 6.9kW Pump pressure 2.7bar Water flow rate 17l/min Plastic water tank 25liters Dimensions L=600 W=725 H=1060mm Power supply 230VAC 50Hz Electrical power consumption 2.1kW Noise level at 10m 51.6dB (A) With IN / OUT external stop valves and connections With control valve and manometer With air flush inlet Electrical connector and water hoses not included |
Magtrol vietnam, Torque Transducers Magtrol, Speed Sensors Magtrol, Brake Systems Magtrol |
| Magtrol 422-214-000-013
Item: LE 214/013 50kN Strain gauge load measuring pin, execution with integrated 2-wire signal amplifier (4-20mA). Nominal load 50kN, axial connector
|
Magtrol vietnam, Torque Transducers Magtrol, Speed Sensors Magtrol, Brake Systems Magtrol |
| Magtrol 422-218-000-013
Item: LE 218/013 500kN Strain gauge load measuring pin, execution with integrated 2-wire signal amplifier (4-20mA). Nominal load 500kN, axial connector |
Magtrol vietnam, Torque Transducers Magtrol, Speed Sensors Magtrol, Brake Systems Magtrol |
| Magtrol 122-216/011/004
Item: LB 216-011/004 100kN, 20m Strain gauge load measuring pin in standard version. Nominal load 100kN integral cable 20m, PG radial |
Magtrol vietnam, Torque Transducers Magtrol, Speed Sensors Magtrol, Brake Systems Magtrol |
| Magtrol 311-201-000-051
Item: 2WB43 Eddy currrent dynamometer including speed probe OS 123 Rated torque 3 Nm at 9550min-1 Maximum braking power 3 kW Maximum speed 50000min-1 |
Magtrol vietnam, Torque Transducers Magtrol, Speed Sensors Magtrol, Brake Systems Magtrol |
| Magtrol 234-410-000-111
Item: DES 410/111 KIT FOR DYNO 2.7 & 43 Kit dynamometer excitation supply for series 2.7 and 43 dynamometer, in aluminium housing, with 5m cable between DES410 and DSP6001/7000 and 1.5m cable between DES410 and dyno |
Magtrol vietnam, Torque Transducers Magtrol, Speed Sensors Magtrol, Brake Systems Magtrol |
